Q347F-25C
DIDTEK
TRBV-CTBV-017
| Availability: | |
|---|---|
| Quantity: | |
The WCB Flanged Trunnion Split Body Ball Valve with Gearbox is a heavy-duty isolation valve for oil, gas, water and compatible industrial fluid pipelines.
Its ASTM A216 WCB carbon steel body uses a side-entry split-body construction that provides structural strength while allowing access to internal components for inspection and maintenance.
The precision-machined trunnion-mounted ball is mechanically supported to distribute line-pressure thrust through the trunnion system. This reduces direct loading on the downstream seat and helps maintain controlled gearbox torque.
The listed configuration is DN200, PN25, worm-gear operated and can use PTFE, RPTFE, nylon, PPL, PEEK or other compatible sealing materials. An ISO 5211 mounting interface supports future pneumatic or electric automation where required.
Parameter Name | Parameter |
Size Range | DN200 |
Pressure Range | PN25 |
Material | WCB |
Trim | Soft Seat: PTFE, RPTFE, NYLON, PPL, PEEK, etc. |
Temperature Range | -196°C ~ 600°C (range listed; confirm by material/trim configuration) |
Design According | API 6D, BS 5351, ASME B16.34 |
Face to Face | ASME B16.10, API 6D |
End Flanges | ASME B16.5, ASME B16.47 |
Butt Welded Ends | ASME B16.25 |
Fire Safety | API 607, API 6A |
Inspection and Test | API 598, API 6D |
Operate | Worm Gear |
Body Type | Split Body |
Seal | PTFE, RPTFE, DEVLON, PEEK, Stellite, Metal |
Suitable Medium | Water, Natural Gas, Oil and compatible corrosive liquids |
Trunnion-Mounted Ball: The mechanically supported ball reduces direct seat loading and helps maintain stable operating torque under pressure.
Split-Body Construction: Side-entry access supports inspection and replacement of seats, seals and internal components during maintenance.
Cavity Pressure Relief: The design can relieve excessive trapped cavity pressure caused by thermal expansion, subject to the selected seat arrangement.
Automation & Backup Sealing: ISO 5211 mounting and optional emergency grease injection support automation and maintenance planning.
Brand | DIDTEK |
Structure | Trunnion Ball |
Material | Carbon Steel / Stainless Steel / Alloy Steel options |
Type | Ball Valve |
Test | 100% quantity tested before delivery |
Guarantee | 18 months after shipment and 12 months after installation |
Delivery | 15 - 60 days |
Sample | Sample available by Didtek Valve |
Color | Customer request |
Packing | Plywood Case |
MOQ | 1 Set |
Certificate | API6D, CE, UKCA, ISO9001, TS, EAC, ISO15848, TA-LUFT, API607, API6FA, etc. |
Place of Origin | Zhejiang, China (Mainland) |
Delivery Detail | Shipped in 15-30 days after payment |
Port | Shanghai or Ningbo |
Payment Terms | L/C, D/A, D/P, T/T, Western Union |
The WCB Trunnion Split Body Ball Valve is designed for general industrial and transmission pipelines that require robust carbon-steel construction, gear operation and maintainable sealing systems.
Oil & Gas Midstream: Suitable for transmission pipelines, compressor stations and distribution systems requiring quarter-turn isolation.
Water Treatment & Utilities: Can be used in industrial cooling water, municipal supply and pumping-station isolation within compatible material limits.
Petrochemical Facilities: Multiple seat and trim options allow configuration for compatible hydrocarbon and process-fluid services.
General Industrial Pipelines: The split body, gearbox and ISO mounting interface provide practical operation and maintenance for large pipeline valves.
