Single Acting With Spring Return Penumatic Actuator Ball Valve With ISO Mounting

Core product positioning

An automated control valve that integrates fault safety protection and standardized installation. Single-acting spring-return pneumatic actuators are adopted. When the air source fails, they automatically return to the preset safe position (fully open or fully closed), and strictly follow the ISO 5211 installation standard to ensure rapid and precise connection with various actuators.

Technical specification parameter table

Core design features

1. Single-acting spring return mechanism

Fail-safe protection

Fault Closure (FC) : The spring-driven valve closes when gas is lost

Fault Opening (FO) : The spring-driven valve opens when gas is lost

Quick response: The spring release time is less than 2 seconds, ensuring rapid action in emergency situations

Low-power design: Only a single gas source control is required, saving energy consumption

2. ISO 5211 standardized installation

Universal interface: Ensures perfect integration with any actuator that complies with ISO standards

Quick replacement: The actuator and valve can be quickly separated for easy maintenance

Precise positioning: Standardized connections ensure the accurate opening and closing positions of the valves

3. High-performance pneumatic actuators

Compact design: Optimized interior space, more efficient torque output

Double-piston structure: It adopts a symmetrical piston design, ensuring smooth operation

Visual position indication: Clearly shows the open and closed status of the valve

Manual operation function: Standard manual override device is provided for convenient debugging and maintenance

Detailed explanation of performance advantages

Safety and reliability

Intrinsic safety: Automatically reset in case of gas source failure, line interruption or emergency shutdown

Explosion-proof options: ATEX and IECEx explosion-proof certifications are optional

Long-life springs: Undergone 1 million fatigue tests to ensure long-term reliability

Operational performance

Fast response: Full travel time 3-5 seconds (depending on the caliber)

Precise control: An optional positioner is available for precise adjustment

Low-friction design: Self-lubricating bearings are adopted to reduce the starting torque

Maintenance convenience

Modular design: Each component can be independently replaced

Online maintenance: Some models support maintenance without stopping

Standardized spare parts: In line with international standards, spare parts are easy to obtain

Typical application fields

Safety-critical system

Chemical plant: Emergency Shutdown System (ESD

Gas pipeline: Emergency shut-off protection

Boiler system: Fuel safety cut-off

Process control

Batch processing process: A procedure that requires automatic reset

Water treatment system: Filtration and backwashing control

Energy Management: Steam Distribution System

Special working conditions

Explosion-proof area: Explosion-proof area for petroleum and chemical industries

Environmental protection equipment: Waste gas treatment system

Food and pharmaceuticals: Occasions requiring sanitary-grade design

Summary

Single-acting spring-return pneumatic actuator ball valve (ISO installation standard) provides industrial automation with: Through the perfect combination of standardized design and fault safety protection

Highest safety level: Ensures automatic reset to a safe position in case of failure

Universal installation standard: ISO interface ensures compatibility with global standard actuators

Reliable operating performance: Strictly tested to ensure long-term stable operation

Convenient maintenance: The modular design reduces maintenance costs and time

Applicable customers: Automation control systems with extremely high requirements for safety and reliability in process industries, energy management, environmental protection engineering, etc.
