Single Acting Pneumatic Ball Valve For Demineralized Water

The Single Acting Pneumatic Ball Valve for Demineralized Water is a high-purity, automated flow control solution engineered specifically for demineralized, deionized (DI), and ultra-pure water systems in power generation, semiconductor manufacturing, and pharmaceutical industries.

Model:
Q641F-16R
Brand:
DIDTEK
Code:
FLBV-CFBV-029

Availability:

Quantity:



Inquire

Demineralized Water Ball Valve Single Acting Pneumatic Ball Valve UPW Pneumatic Ball Valve Stainless Steel 316L Ball Valve Spring Return Pure Water Valve

Product Detail

Product Parameters

Parameters

Application & Function

Product Detail

The Single Acting Pneumatic Ball Valve for Demineralized Water is a high-purity, automated flow control solution engineered specifically for demineralized, deionized (DI), and ultra-pure water systems in power generation, semiconductor manufacturing, and pharmaceutical industries. Because demineralized water is highly aggressive and prone to leaching metallic ions, this valve features wetted components made from high-purity ASTM A351 CF8M / 316L stainless steel with controlled low-carbon content and superior surface polishing. Equipped with a reliable single-acting (spring-return) pneumatic actuator, it ensures automatic fail-safe positioning (fail-close) during a sudden loss of air supply, protecting sensitive high-purity piping loops. Virgin PTFE or TFM seat inserts are utilized to prevent media contamination and ensure absolute bubble-tight shut-off. A-29 DIDTEKCFBV-Single Acting Pneumatic Ball Valve For Demineralized Water

Product Parameters

Parameter Name	Parameter
Size Range	DN100
Pressure Range	PN16
Material	CF8M
Seal	Soft Seat: RPTFE
Temperature Range	-29°C~120°C
Design According	ISO 17292
Face to Face	EN 558-1
End Flanges	EN 1092-1
End Connection Type	RF
Fire Safety	API 6FA
Inspection and Test	EN 12266-1
Operate	Pneumatic
Body Type	Split Body
Type of Valve	Floating Ball Valve
Suitable Medium	Water, Oil, Gas

Design Description

High-Purity 316L Construction: Wetted surfaces are precision-machined from low-carbon 316L stainless steel with superior surface finishes to prevent microbial growth and particle shedding.
Fail-Safe Spring-Return Operation: The single-acting pneumatic actuator utilizes spring force to automatically return the valve to a safe position during emergency air or power loss, safeguarding pure water processes.
Contamination-Free Sealing (PTFE/TFM): Utilization of virgin PTFE or modified TFM seat materials prevents chemical leaching, maintaining the high resistivity and low conductivity of demineralized water.
Bubble-Tight Zero Leakage: Engineered for dependable on/off isolation in low-viscosity, high-purity fluid lines without risking seat degradation.

Parameters

Brand	DIDTEK
Structure	Floating Ball
Material	CF8M
Type	Cast Ball Valve
Test	100% quantity tested before delivery
Guarantee	18 months after shipments and 12 months after installed
Delivery	15 - 60 days
Sample	Sample Available by Didtek Valve
Color	Customer request
Packing	Plywood Case
MOQ	1 Set
Certificate	API6D, CE, UKCA, ISO9001, TS, EAC, ISO15848, TA-LUFT, API607, API6FA etc.
Place of Origin	Zhejiang, China (Mainland)
Delivery Detail	Shipped in 15-30 days after payment
Port	Shanghai Or Ningbo
Payment Terms	L/C,D/A,D/P,T/T, Western Union

Application & Function

Single Acting Pneumatic Ball Valve For Demineralized Water are widely utilized in demanding environments due to their superior material properties:

Power Generation Plants: Demineralized water makeup systems for supercritical boilers and steam turbine condensate loops.
Semiconductor & Electronics: Ultra-pure water (UPW) pre-treatment and distribution piping loops.
Pharmaceutical & Biotech: Purified water (PW) and water-for-injection (WFI) pre-distribution lines.
