Split Body Pneumatic Operation Floating Ball Valve

Product Overview

The split-type pneumatic floating ball valve is a high-performance valve that combines a modular split structure with pneumatic automatic control. The product adopts a two-piece valve body design and floating ball sealing principle, and is equipped with a high-performance pneumatic actuator to achieve rapid opening and closing actions and reliable shut-off functions. It is an ideal control device for modern industrial automation pipelines.

Technical specifications

Product features

1. Split valve body structure

Quick maintenance: The valve body can be quickly disassembled into two parts, facilitating the inspection and replacement of internal components

Online maintenance: No need to disassemble the pipeline, significantly reducing downtime

Reliable sealing: The body gasket adopts a spiral winding structure to ensure zero leakage of the valve body

2. Pneumatic actuator system

Fast response: Single-acting/double-acting cylinders achieve rapid opening and closing within 1 to 5 seconds

Intelligent control: Optional accessories such as solenoid valves, limit switches, and positioners are available

Safety fault: The spring return type can automatically return to its original position (fault on/off) when depressurized.

3. Floating ball sealing technology

Self-tightening seal: The medium pressure pushes the ball to press against the valve seat, achieving pressure-assisted sealing

Bidirectional blocking: The carefully designed preload ensures reliable bidirectional sealing performance

Low flow resistance design: The full-bore structure ensures minimal fluid pressure loss

4. Safety protection design

Fire safety: Complies with API 607 standard. A metal seal is formed after the soft seal fails

Anti-static structure: A static electricity path is formed between the ball, valve stem and valve body

Anti-blowout valve stem: The bottom T-shaped structure design ensures the safety of high-pressure operation

Application field

1. Automated process

Control of automated production lines

Batch processing system

Remote control of pipeline

2. Public Utilities

Compressed air system

Cooling water circulation

Energy management system

3. Process control

Chemical process control

Oil and gas transportation system

Water treatment device

4. Special applications

Control of hazardous media

Quick cut-off system

Application in explosion-proof areas

Summary

The API 6D A105 RTJ 1500LB high-pressure side-mounted floating ball valve is perfectly combined through strict API standards, high-quality material selection and professional high-pressure design, providing industrial users with:

Absolute high-pressure reliability: Class 1500 pressure rating, with outstanding pressure-bearing capacity

Standard compliance: Complete API 6D certification ensures reliable quality

Convenient maintainability: The side-mounted structure enables rapid online maintenance

Long service life: Designed for 30 years, with the lowest maintenance cost

This product is an ideal choice for high-pressure pipeline systems, process equipment and energy devices, providing the most reliable high-pressure cut-off solution for industrial fluid control.
