High Temperature 6inch 600LB Metal Seated Trunnion Ball Valve

Didtek 6-inch 600LB High-Temperature Metal Seated Trunnion Ball Valve is a premium fluid control solution engineered for extreme industrial environments.

Model:
Q347-900LBC
Brand:
DIDTEK
Code:
TRBV-CTBV-009

Availability:

Quantity:



Inquire

High Pressure Ball Valve Metal seated ball valve High Temperature Ball Valve Metal to Metal Ball Valve Ball Valve manufacturers Gear Operated Ball Valve 2PC ball valve solid ball valve 6in ball valve Metal seated trunnion ball valve

Product Detail

Product Parameters

Parameters

Application & Function

Product Detail

The Didtek 6-inch 600LB High-Temperature Metal Seated Trunnion Ball Valve is a premium fluid control solution engineered for extreme industrial environments. Utilizing advanced Ni60 Nickel-based alloy hard-facing, the ball and seat surfaces achieve exceptional hardness and wear resistance. Combined with a Metal-to-Metal sealing design, it maintains superior zero-leakage performance under 600LB high pressure and fluctuating thermal conditions. Its trunnion-mounted structure and precision engineering ensure extended service life and low maintenance costs during the transport of aggressive media.

A-9 DIDTEKCTBV-High Temperature 6inch DBB 600LB+K11 Metal Seated Ni60 Nickel Trunnion Ball Valve

Product Parameters

Parameter Name	Parameter
Size Range	6"
Pressure Range	900LB
Material	WCB
Trim	Soft Seat: PTFE, RPTFE, NYLON, PPL, PEEK, etc.
Temperature Range	-196°C~600°C
Design According	API6D, BS5351, ASME B16.34
Face to Face	ASME B16.10, API6D
End Flanges	ASME B16.5, ASME B16.47
Butt Welded Ends	ASME B16.25
Fire Safety	AP1607,API6A
Inspection and Test	API 598,API6D
Operate	Worm Gear
Body Type	Split Body
Seal	PTFE, Rptfe, Devlon, Peek, Stellite,Metal
Suitable Medium	Water, Natual Gas, Oil and some corrosive liquid

Design Description

✔️ Structure : 2 pieces or 3 pieces body
✔️ High shut-off sealing mechanism and low torque operation
✔️ Block and bleed function
✔️ Self-cavity pressure relief
✔️ Fire safe design
✔️ Blow out proof stem construction
✔️ Anti-static design
✔️ Locking device (for lever handle operation)
✔️ ISO 5211 actuator mounting
✔️ Emergency grease injection (option)
✔️ PN design can be available

Parameters

Brand	DIDTEK
Structure	Trunnion Ball
Material	Carbon Steel, Stainless Steel, Alloy Steel, CI, DI etc.
Type	Cast Steel Ball Valve
Test	100% quantity tested before delivery
Guarantee	18 months after shipments and 12 months after installed
Delivery	15 - 60 days
Sample	Sample Available by Didtek Valve
Color	Customer request
Packing	Plywood Case
MOQ	1 Set
Certificate	API6D, CE, UKCA, ISO9001, TS, EAC, ISO15848, TA-LUFT, API607, API6FA etc.
Place of Origin	Zhejiang, China (Mainland)
Delivery Detail	Shipped in 15-30 days after payment
Port	Shanghai Or Ningbo
Payment Terms	L/C,D/A,D/P,T/T, Western Union

Application & Function

Didtek High Temperature 6inch 600LB Metal Seated Trunnion Ball Valve are widely utilized in demanding environments due to their superior material properties:

Refining & FCC: Handling high-temperature oil slurry, catalysts, and coking media.
Polysilicon & Chemical Processing: Ideal for processes involving high-temp silicon powder and aggressive chemicals with particulates.
Power Generation: Used in boiler blowdown, steam trap systems, and high-pressure steam control.
Coal Chemical (CTL): Excels in coal slurry, black water, and grey water applications where extreme abrasion resistance is mandatory.
