RPTFE Seat Insert ANTI Blow Out Stem Split Body Trunnion Ball Valve
Applicable Standards:
Ball Valve design according to API6D,BS5351,ASME B16.34
Face to face ASME B16.10,API6D
End Flanges ASME B16.5/ASME B16.47
Butt welded ends ASME B16.25
Fire Safety API607,API6A
Inspection and test API 598,API6D
Material: CF8M
Size Range: 2"~48"
Pressure Rating: ASME CL, 150, 300, 600
Design Description:
- Structure : 2 pieces or 3 pieces body
- High shut-off sealing mechanism and low torque operation
- Block and bleed function
- Self-cavity pressure relief
- Fire safe design
- Blow out proof stem construction
- Anti-static design
- Locking device (for lever handle operation)
- ISO 5211 actuator mounting
- Emergency grease injection (option)
- PN design can be available
| Brand | DIDTEK |
| Structure | Ball |
| Valve Material | Didtek provide cast steel, stainless steel, special alloy, CI, DI etc |
| Valve Type | Didtek Produce Ball Valve |
| Valve Test | 100% quantity tested before delivery |
| Valve Guarantee | 18 months after shipments and 12 months after installed |
| Valve Structure | Tunnion Mounted Ball Valve |
| Valve Delivery | 15 - 30 days |
| Valve Sample | Sample Available by Didtek Valve |
| Valve Color | Customer request |
| Valve Packing | Plywood Case for Ball Valve |
| MOQ | 1 Set |
| Valve Certificate | API6D/CE/ISO9001/ISO14001 |
| Place of Origin | Zhejiang, China (Mainland) |
| Delivery Detail: | Shipped in 15-30 days after payment |
| Port | Shanghai Or Ningbo |
| Payment Terms | L/C,D/A,D/P,T/T, Western Union |
Application & Function:
Didtek Cast Trunnion Ball Valve have been designed for severe oil and gas applications, including production, transportation and distribution.
Didtek Cast Trunnion Ball Valve designed the Side-Entry Trunnion-Mounted Ball Valves to assure bi-directional sealing of the valve with two independent floating seats. The design of these seats minimizes the torque required to operate the valve without losing the sealing power. This power is assured by zero differential pressure to the valve’s maximum rated pressure. In addition, these repairable valves are manufactured to seal off both seats at the same time and to allow bleeding of the entrapped cavity pressure (DBB) with the ball in the closed position. The DBB feature allows for verifying that the seats are properly sealing.
